4000lm 3LCD Super Short Throw 4K DLP Projector DMD Chip For Family Classroom

Brand Name:	Yeoan
Model Number:	YA371
MOQ:	50
Payment Terms:	L/C, T/T, Western Union

Detail Information

Product Description

Detail Information

Certification:

CCC CE CB FCC

Brightness:

4000lm

Display Technology:

3LCD

Projection Light Source:

Lamp

Projection Size:

50-100"

Throw Ratio:

0.46：1

Projectioin Screen:

30-300 Inch

Aspect Ratio:

Native:16:10 Compatible: 4:3/16:9

Keystone Correction:

V: ±30° H：±15°

Built-In Speakers:

Yes

Contrast Ratio:

15000:1

Packaging Details:

Packaging Box Dimensions (WxDxH mm): 34.7cm x 34.1cm x 10.9cm (13.6" x 13.4" x 5.6")

Highlight:

4000lm 4K DLP Projector

DMD chip 4K DLP Projector

4000lm dlp chip projector

Product Description

4000lm 3LCD Super Short Throw 4K DLP Projector DMD Chip For Family Classroom

Key Features

Attribute	Value
Brightness	4000lm
Display Technology	3LCD
Projection Light Source	Lamp
Projection Size	50-100"
Throw Ratio	0.46：1
Projection Screen	30-300 inch
Aspect Ratio	Native:16:10 Compatible: 4:3/16:9
Keystone Correction	V: ±30° H：±15°
Built-In Speakers	Yes
Contrast Ratio	15000:1

Product Overview

This Ultra short throw projector can project an 80-inch image from just 0.75 meters away, delivering an extraordinary big-screen experience in limited spaces. The high contrast ratio of 15000:1 ensures rich image layering with exceptional detail, providing clear, sharp images for demanding audiences.

Using the latest frequency conversion driving technology, the projector offers extended lamp life up to 10,000 hours in ECO mode, significantly reducing operating costs. With 4000 lumens brightness, the picture remains clear even in bright light environments, maintaining excellent visibility when projected directly onto a white wall.

Technical Specifications

Model	YA \| YA371
Display Technology	LCD panel (x 3, R/G/B)
LCD Panels	SONY 3*0.64"
Brightness	4000 lumens
Resolution	XGA (1024*768)
Contrast	15000:1
Lens	F1.8, f=6.08mm Fixed zoom, Manual focus lens
Uniformity	90%
Throw ratio	0.46 : 1 (80" @ 0.75cm)
Aspect ratio	4:3 support 16:9
Projection distance	0.50m~1.00m
Projection size	50:100 inch
Lamp power (Life)	218w (Normal 6000 hrs. Economic 10000 hrs.)
Keystone correction	V. ±30° (Auto/Manual) H. ±15° (Manual), Pincushion/Barrel Correction, Corner Keystone
Input	1-HDMI in MHL, 1-HDMI, Audio: 3.5 Mini-Jack, Video, 2-VGA, YCbCr/Component/S-Video (Share with VGA in 1) USB-A (Support memory viewer/optional Wi-Fi dongle) 2-Audio-In (L/R), USB-B (Display), RJ45 (Display)
Output	VGA (Share with VGA in 2), Audio Out
Control	RS232, RJ45, USB-B (FW upgrade)
PC Compatibility	VGA, SVGA, XGA, SXGA, WXGA, UXGA, WUXGA, Mac
Video Compatibility	PAL, SECAM, NTSC 4.43, PAL-M, PAL-N, 480i, 480p, 576i, 576p, 720p, 1080p and 1080i
Scanning Frequency	H: 15~100Khz, V: 48~85Hz
Noise	Normal mode 37dB, Economic mode 33dB
Projection	Front, Rear, Desktop, Ceiling
Speakers	10W*1
Power Consumption	Max 270 Watts
Power Supply	100V - 240V @ 50 - 60Hz
Operating Temp.	0°C - 40°C (Over 35°C Go to ECO Mode)
Storage Temp.	-20°C - 60°C
OSD Languages	26 languages including English, German, French, Spanish, Japanese, Chinese, Russian, Arabic and more
Dimensions (W x H x D)	34.7cm x 34.1cm x 10.9cm (13.6" x 13.4" x 5.6")
Weight	4Kg

Included Accessories

Power Cord
Remote Control
VGA Cable

Optional Accessories

Replacement lamp module
Wi-Fi display module
HDMI cable
Screen
Bracket

Additional Features

One Touch Lamp Replacement
Quick Power OFF
Customized Startup Logo
Auto Image Reverse
Build in Test Images
Corner Keystone
