RGB LCD Display Wall Mount Advertising Touch Screen Monitor 15.6 Inch ODM

Brand Name:	YEOAN
Model Number:	TA-156
MOQ:	100
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Mounting Type:

Wall Mounted

Display Type:

LCD

Screen Size:

15.6 Inch

Power Supply:

AC 100-240V, 50/60Hz

Viewing Angle:

178°

Response Time:

30 Ms

Contrast Ratio:

3000:1

Resolution:

1920x1080

Brightness:

250 Cd/m²

Touch Screen:

Yes

Connectivity:

HDMI, VGA, USB

Operating System:

Android Or Windows

Language Menu:

English,Chinese And Other Languages

Metal Shape:

Can Be Customized

Frame Colour:

Can Be Customized

Starting Up:

Auto-loop Playback

Packaging Details:

Packing carton: 450*310*110 mm

Highlight:

RGB LCD Display Wall Mount

ODM LCD Display Wall Mount

ODM advertising lcd display

Product Description

RGB LCD Display Wall Mount Advertising Touch Screen Monitor 15.6 Inch ODM

Product Specifications

Attribute	Value
Mounting Type	Wall mounted
Display Type	LCD
Screen Size	15.6 inch
Power Supply	AC 100-240V, 50/60Hz
Viewing Angle	178°
Response Time	30 ms
Contrast Ratio	3000:1
Resolution	1920x1080
Brightness	250 cd/m²
Touch Screen	Yes
Connectivity	HDMI, VGA, USB
Operating System	Android or Windows
Language Menu	English, Chinese and other languages
Metal Shape	Can be customized
Frame Colour	Can be customized
Starting Up	Auto-loop playback

Product Description

HDMI Small Wall Mounted Advertising Display Touch Screen Monitor 15.6 Inch

Playback Method

Insert the U disk/SD card with pictures, videos and other materials into the advertising machine, and automatically play in a loop.

Function Display

Equipped with 8G SD card storage
The vertical screen source cannot be automatically converted, and needs to be converted to split screen playback through computer software
Vertical screen and split screen playback need to be made
Recommended to use the smart stand-alone version

Supported Formats

Image format: JPG/PNG/BMP (color mode is RGB)
Video format: AVI, MP4, MPG, MOV, etc. [Speed 25-30FPS or less, video code stream supports a maximum of 20M/S]
Music format: MP3, WMA

The product uses original A-level panels from BOE/AUO/LG, and can be used with Android, Windows, or domestically produced information and innovation platforms such as Lin and Tongxin infrared, nano, capacitance, and Shida, etc, to meet customers' actual application needs in multiple scenarios.

The integrated cold rolling process of metal stamping, the matching of the profile frame, and the high-transmittance tempered glass have a grand and stable appearance and are widely used in business, administration, education, entertainment and other fields.

Technical Specifications

Parameter	15.6"	18.5"
Panel size	15.6"	18.5"
Resolution	1920*1080(pixels)	1920*1080(pixels)
Pixel pitch	0.18*0.18 mm	0.21*0.21 mm
Brightness	250cd/m² (typ.)	250cd/m² (typ.)
Contrast	3000:1 (typ.)	1200:1 (typ.)
Color	16.7M (8bit)	16.7M (8bit)
Response time	30ms (typ.)	14ms (typ.)
Viewing area (H*V)	344.16*193.59 mm	409.8*230.4 mm
Angle (H*V)	178° / 178°	178° / 178°
Service life	30,000 hrs (typ.)	30,000 hrs (typ.)

Mainboard Parameters (Optional)

Parameter	15.6"	18.5"
Mainboard	352 motherboard (2K solution)	RK3566 motherboard (2K solution)
Running system	Android 9.0	Android 11
Chip	Hi3751 Quad Core cortex A53 Frequency 1.0GHz	RK3566 Quad Core cortex A55 Frequency 1.8GHz
Memory	1G	2G
Storage	8G	16G
Network	100M Ethernet/WiFi-2.4G	100M Ethernet/WiFi-2.4G

Physical Specifications

Parameter	15.6"	18.5"
Housing Material	Aluminum frame + tempered glass + metal back cover	Aluminum frame + tempered glass + metal back cover
Shell color	Silver + black frame + black back cover	Silver + black frame + black back cover
Bare metal size (WHD)	376.4236.452.2 mm	443.4267.456.2 mm
External dimensions of packaging (WHD)	450310110mm	520345110 mm
VESA hole	100100mm, 4M4 screw	100100mm, 4M4 screw
Net weight	3.5KG	4KG
Gross Weight	4KG	4.5KG

Included Accessories

Remote Control *1
Power cord *1
Warranty card *1
Certificate *1
Wall Mount *1

Welcome to customize the different size of the display screen.
