Home / Products / Large Venue Laser Projectors /

IP5X Dynamic Led LCD DLP Large Venue Laser Projector 500 Inch Huge Screen

IP5X Dynamic Led LCD DLP Large Venue Laser Projector 500 Inch Huge Screen

IP5X Dynamic Led LCD DLP Large Venue Laser Projector 500 Inch Huge Screen

Brand Name: Yeoan
Model Number: YAC841
MOQ: 5
Payment Terms: L/C, T/T, Western Union
Detail Information
Product Description
Detail Information
Brightness:
8400lm
Standard Resolution:
WUXGA (1920 X 1200)
Display Technology:
DLP
Projection Light Source:
Laser
Projection Screen:
60-500"
Lens Optional:
Yes
Standard Lens Ratio:
1.17~1.88：1
Contrast Ratio:
5,000,000:1
Aspect Ratio:
Native:16:10 Compatible: 4:3/16:9
Focus Mode:
Manual
Keystone Correction:
V：±30° 4 Corner Correction
Lens Shift:
V:＋50%～10%、 H:±8%
Packaging Details:
Packaging Box Dimensions (WxDxH mm): 574（W)*554(D)*268(H)
Highlight:

IP5X large venue laser projector

,

dynamic Led large venue laser projector

,

IP5X led lcd projector

Product Description
IP5X Dynamic LED LCD DLP Large Venue Laser Projector
500 Inch Huge Screen WUXGA High Resolution
Key Features:
  • 500-inch projection capability for immersive viewing experience
  • 30,000 hours laser light source life (ECO mode)
  • 5,000,000:1 dynamic contrast ratio for superior image quality
  • Low 39dB noise operation for minimal distraction
  • HDBaseT interface for high-definition signal transmission
  • Built-in 10W speaker system
  • 3D video mode support
  • IP5X-certified optical engine
IP5X Dynamic Led LCD DLP Large Venue Laser Projector 500 Inch Huge Screen 0
Technical Specifications
Brightness 8400lm (Max), 7560lm (Typical), 6720lm (Min)
Resolution WUXGA (1920 x 1200)
Display Technology DLP (0.67" DMD)
Light Source Laser (20,000-30,000 hours life)
Screen Size 60-500 inches
Contrast Ratio 5,000,000:1
Aspect Ratio Native 16:10 (Compatible 4:3/16:9)
Throw Ratio 1.17-1.88:1 (Standard lens)
Zoom Ratio 1.6
Lens Shift Vertical: +50% to -10%, Horizontal: ±8%
Keystone Correction Vertical: ±30°, 4 Corner Correction
Noise Level 39dB (Normal), 36dB (ECO)
Installation Flexibility
  • 360° projection capability for versatile mounting
  • Multiple projection methods: front, rear, ceiling/front, ceiling/rear
  • Auto ceiling projection mode
  • Integrated image warping and blending
  • Lens position memory for quick setup
  • Optional five lenses from standard long throw to short throw
Connectivity
  • 2x VGA inputs
  • 2x HDMI 1.4B inputs
  • 1x HDBaseT (Optional)
  • 1x Video input
  • Audio inputs (RCA and 3.5mm)
  • Control interfaces: RS232, RJ45
Applications

Ideal for large venues including:

  • Meeting rooms and auditoriums
  • Museums and houses of worship
  • Broadcast environments
  • Educational institutions
  • Corporate offices and hotels
Physical Specifications
Dimensions (WxDxH) 460 x 355 x 142.6 mm
Net Weight ~10kg
Shipping Weight 12.5kg
IP5X Dynamic Led LCD DLP Large Venue Laser Projector 500 Inch Huge Screen 1
